Winters PFP830 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/2,000 psi/kPa, 0.25" bottom

Modèle: PFP830 | CUP: 628311242706

Winters PFP830 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/2,000 psi/kPa, 0.25" bottom-

L'image est pour référence seulement, référez-vous à l'information sur le produit pour tous les détails.


Télécharger: datasheet

Winters PFP830 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/2,000 psi/kPa, 0.25" bottom

Modèle: PFP830 | CUP: 628311242706

The premium stainless-steel, liquid-filled pressure gauge with 2.5" (6.4 cm) dial comes with a 0.25" (0.64 cm) bottom connection and a range of 0/2,000 psi/kPa. It is highly accurate with an accuracy rate of ±1.5% of full-scale value. It features stainless-steel internals and a case that protects it against vibration and pulsation. Dual scale.

The premium stainless-steel, liquid-filled pressure gauge with 2.5" (6.4 cm) dial comes with a 0.25" (0.64 cm) bottom connection and a range of 0/2,000 psi/kPa. It is highly accurate with an accuracy rate of ±1.5% of full-scale value. It features stainless-steel internals and a case that protects it against vibration and pulsation. Dual scale.

Prix spécial $132.21 CAD
Prix régulier $167.36 CAD
Disponibilité 2 à 3 semaines
Quantité

Winters PFP830 Offers

The premium stainless-steel, liquid-filled pressure gauges with 2.5" (6.4 cm) dial come with a 0.25" (0.64 cm) bottom connection. They are highly accurate with an accuracy rate of ±1.5% of full-scale value. These gauges feature stainless-steel internals and a case that protects against vibration and pulsation. Dual scale.

Features

  • Liquid-filled, stainless-steel case protects against vibration and pulsation
  • Highly accurate
  • Back, bottom or panel mounted
  • Under and overload stops
  • Ventable plug on 2.5" to 4.5" (6.35 to 11.4 cm) stainless-steel and 4.5" (11.4 cm) brass bottom mount and 4" (10.2 cm) stainless-steel back mount gauges
  • Stainless steel or brass wetted parts
  • Restrictor screw standard on dual scale (optional on single scale)
  • Dry case available
  • ASME B40.100 compliant (EN837-1 available)
  • RoHS compliant (SS internals only)
  • CRN registered
  • 5-year warranty

Applications

  • Outdoor And Severe Ambient And Process Conditions
  • Use Where Harmful Vibration And Pulsation Are Present
  • Hydraulic Equipment, Pressure Washers, Oil Field Equipment, Pumps, Compressors And Process Systems

Winters PFP830 Specifications

Range 0/2,000 psi/kPa
Connection 0.25" (0.64 cm) bottom
Dial 2.5" (63 mm) white aluminum with black and red markings
Case AISI 304 SS
Lens Polycarbonate, high pressure BSP(G) and HP: tempered safety glass
Ring AISI 304 SS
Fill Liquid Glycerin
Working Pressure Maximum 75% of full-scale value
Ambient/Process Temperature -4 to 150°F (-20 to 65°C)
Accuracy ±1.5% of full scale
Cliquer ici pour toutes les spécifications du Winters PFP830

Le Winters PFP830 comprend

  • Winters PFP830 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/2,000 psi/kPa, 0.25" bottom

Poser une question sur le Winters PFP830 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/2,000 psi/kPa, 0.25" bottom
