An infrared leak detector equipped with an infrared sensor that quickly and easily identifies the smallest refrigerant leaks. This device can detect all CFC, HCFC, HFC, and HFO refrigerants, including R-134A, R-404A, R-410A, and R-1234YF.
An infrared leak detector equipped with an infrared sensor that quickly and easily identifies the smallest refrigerant leaks. This device can detect all CFC, HCFC, HFC, and HFO refrigerants, including R-134A, R-404A, R-410A, and R-1234YF.
The Yellow Jacket AccuProbe 69320 is an infrared (IR) leak detector designed to quickly and easily identify the smallest leaks. It detects all CFC, HCFC, HFC, and HFO refrigerants, including R-134A, R-404A, R-410A, and R-1234YF. The IR leak detector features a smart alarm LED that indicates the size of the leak on a rising scale. With two sensitivity modes, this AccuProbe will detect leaks of any size, except for hydrocarbons.
Caractéristiques
Applications
| Sensor Type | Infrared |
| Minimum Sensitivity | 0.1 oz/ yr. (3 g/yr.) |
| Calibration | Automatic |
| Response Time | Instantaneous |
| Battery Type | Lithium Ion |
| Battery Life | 8 hours |
| Fast Charge Time | Approx 3 hours |
| Battery (receiver) | 1 x 9 V Alkaline (included) |
| Holds Charge When Not In Use | 9 months (app.) |
| Charging Input Type | Micro USB |
| Input Voltage | 5 V (dc) ±5% |
| Input Current | 1 A ±5% |
| Storage Temperature | -4 to 140°F (20 to 60°C) |
| Operating Temperature * | -4 to 122 °F (20 to 50°C) |
| Charging Temperature | 32 to 113°F (0 to 45°C) |
| Humidity | 95% RH NC maximum |
| Altitude | 6500' (2000 m) |
| Pollution Degree | 2 |
| Overvoltage Category | 2 |
| Body Material | ABS |
| Probe Length | 17" (430 mm) |
| Weight | 0.84 lbs (0.38 kg) |
Cliquer sur une catégorie pour voir une sélection d'accessoires compatible avec le Yellow Jacket 69320 AccuProbe IR Refrigerant Leak Detector with Infrared Sensor.
