This dual LED source is a general-purpose test source for multimode systems at 850 and 1300 nm. Typical applications include fiber optic attenuation measurement, polarity testing, and fiber identification on critical systems.
This dual LED source is a general-purpose test source for multimode systems at 850 and 1300 nm. Typical applications include fiber optic attenuation measurement, polarity testing, and fiber identification on critical systems.
Caractéristiques
| Output Wavelength | Port 2: 850 and 1300 nm LED |
| Output Power | -20 dBm ±1 dB (at 62.5/125 μm) |
| Adjust Output Power | Adjustable over 7 dB in 0.01 dB steps |
| Short Term Stability | 0.01 dB |
| Stability Over Temperature | 0.35 dB (typical) |
| Wavelength Drift | 0.4 nm per °C (typical) |
| Mode Controlled Source | 50/125μm compliant:
|
| Reconnection Repeatability at 95% Confidence | 0.05 dB |
| Calibration Validity ISO/IEC 17025 | 3 years |
| Modulated Output | 270 Hz 1 kHz 2 kHz ±2% 12 Multi-Fiber ID tones |
| Autotest (not available for 470 and 540 nm LED sources) | Compatible with KI Autotest power meter port and matching λ |
| Power | Battery External power via USB |
| Battery Types | 2 x AA (LR6) Alkaline 2 x AA NiMH AA (rechargeable via USB) |
| Battery Life | Laser/LED source: 90/80 hours in Autotest, typical |
| Auto Off | Selectable |
| Case | Polycarbonate (body) Rubber (edges and corners) Moisture resistance 1-meter drop tested |
| Temperature | Operating temperature: 5 to 131°F (-15 to 55°C) Storage temperature: -13 to 158°F (-25 to 70°C) |
| Relative Humidity | 0 to 95% |
| Warranty | 3 years |
| Dimensions | 7.5 x 4.1 x 1.4" (190 x 105 x 35 mm) |
| Weight | 0.92 lbs (0.42 kg) |
| Shipping Weight | 3.3 lbs (1.5 kg) |
