L'image est pour référence seulement, référez-vous à l'information sur le produit pour tous les détails.
With a 3' hose, this pneumatic hand pump features 650 psi (45 bar) and a 500 psi gauge with 0.25% full scale accuracy.
With a 3' hose, this pneumatic hand pump features 650 psi (45 bar) and a 500 psi gauge with 0.25% full scale accuracy.
Features
| Fine Adjustment Resolution | .001 |
| Temperature Range | -4 to 185°F (-20 to 85°C) |
| Digital Pressure Gauge | 0 to 500 psig ± 0.25% full scale accuracy |
| FieldLab Pressure Reference | 500 psi 35 bar 3.5 MPa female quick-test bottom connection |
| Process Connection | 1/4" male NPT bottom connection |
| Hose | Quick-test 6900 psi Stainless steel hose ends 3" (92 cm) |
| Length | 3.53" (8.9 cm) |
| Fine Adjustment Resolution | .001 |
| Temperature Range | -4 to 185°F (-20 to 85°C) |
| Digital Pressure Gauge | 0 to 500 psig ± 0.25% full scale accuracy |
| FieldLab Pressure Reference | 500 psi 35 bar 3.5 MPa female quick-test bottom connection |
| Process Connection | 1/4" male NPT bottom connection |
| Hose | Quick-test 6900 psi Stainless steel hose ends 3" (92 cm) |
| Length | 3.53" (8.9 cm) |
