An intelligent, dual vision temperature screener equipped with a high-definition visible light camera and infrared thermal imager that provides accurate and rapid skin temperature screening. It is ideal for screening public areas, provides data logging capabilities, and issues alert when persons with elevated skin temperature are present.
An intelligent, dual vision temperature screener equipped with a high-definition visible light camera and infrared thermal imager that provides accurate and rapid skin temperature screening. It is ideal for screening public areas, provides data logging capabilities, and issues alert when persons with elevated skin temperature are present.
Features
Applications
Note d'application: La détection de températures corporelles élevées est souvent notre première ligne de défense
Le but de ce dépistage est de différencier les personnes en bonne santé de celles qui ont de la fièvre. Nous vous expliquerons comment utiliser correctement les instruments et comment évaluer les résultats qu'ils vous fournissent.
Lire notre note sur la façon de détecter la température corporelle
| Temperature Measurement and Alarm | |
| Temperature Range | Optimal: 91 to 104°F (33 to 40°C) Maximum: 82 to 113°F (28 to 45°C) |
| Temperature Accuracy | Without blackbody: ≤±0.5°F (≤±0.3°C); (optimal range) |
| Measurement Distance | 3.5 to 6.5' (1 to 2 m) |
| Calibration | Human subject or blackbody |
| Target Mode | Single or multiple person |
| Intelligent Tracking | Automatic tracking and highest temperature readout |
| Temperature Alert | User defined threshold value |
| Thermal Camera | |
| Sensor Technology | Uncooled Vox Microbolometer |
| Resolution | 160 x 120 |
| NETD | <50 mK (0.050 °C) |
| FOV | 57 x 44° |
| Color Palettes | Iron red |
| Visible Camera | |
| Sensor Technology | 1/2.9" CMOS |
| Pixel Size | 2 MP |
| Resolution | 1920 x 1080 |
| Low Light Level | Color: 0.1 Lux at (F1.2)/B&W: 0.01 Lux at (F1.2) |
| Wide Dynamic | Supported |
| Color Balance | Supported |
| Digital Noise Reduction | 3D digital noise reduction |
| General | |
| Operating Temperature | 50 to 113°F (0 to 45°C) Preferred: 60 to 90°F (16 to 32°C) |
| Humidity | EC 60068-2-30/24h 85% RH |
| Power Adaptor | Input: 100 to 240 VAC Output: 15 V 2 A DC |
| Dimensions | 3.75 x 3.5 x 1.6" (95 x 88 x 40 mm) |
| Weight | 12.3 oz (348 g) |
Cliquer sur une catégorie pour voir une sélection d'accessoires compatible avec le Planck TC160 ThermaCheck EBT Screening System.
