Mesure la tension c.a. et c.c. jusqu'à 600V avec une résolution numérique précise. Mesure de courant OpenJawMC vous permet de vérifier le courant jusqu'à 100A sans ouvrir le circuit.
Mesure la tension c.a. et c.c. jusqu'à 600V avec une résolution numérique précise. Mesure de courant OpenJawMC vous permet de vérifier le courant jusqu'à 100A sans ouvrir le circuit.
| General Specifications | |
| Jaw Opening | 0.5" (12.9 mm) |
| Max Wire Size | 1/0 THHN Cable |
| Current Range AC RMS | 0 to 100.0 A |
| Accuracy AC Current (50/60 Hz) | 3% ± 3 counts |
| AC Response | Averaging |
| Voltage Range AC | 0 to 600 V |
| Accuracy AC Voltage | 1.5% ± 2 counts |
| Voltage Range DC | 0 to 600 V |
| Accuracy DC Voltage | 1% ± 1 count |
| Resistance Range | 0 to 1000 Ω |
| Continuity Beeper Threshold | On at <25 Ω, off at >400 Ω |
| Volts Indicator LED Threshold | Guaranteed on by 30 V AC |
| Environmental Specifications | |
| Operating Temperature | 50 to 122°F (10 to 50°C) |
| Storage Temperature | -22 to 140°F (-30 to 60°C) |
| Humidity (Without Condensation) | 0 to 95% at 41 to 86°F (5 to 30°C) 0 to 75% at 86 to 104°F (30 to 40°C) 0 to 45% at 104 to 122°F (40 to 50°C) |
| Dust/Water Resistance | Yes |
| Operating Altitude | 6561.7' (2000 m) |
| Temperature Coefficient | 0.1 x (specified accuracy)/°C (<18°C or >28°C) |
| Safety Specifications | |
| Overvoltage Category | CAT III 600 V ac/dc (EN61010-1) |
| Agency Approvals | CSA, TUV and CE |
| Maximum Voltage | Between any terminal and earth ground |
| Mechanical Specifications | |
| Calibration Cycle | One-year |
| Current Sensor Opening | 0.5" (12.9 mm) |
| Low Battery Indicator | Yes |
| Battery Type | 2 x AA batteries |
| Battery Life | 200 hour zinc chloride, 400 hour alkaline |
| Dimensions | 1.2 x 2 x 8" (30.5 x 51 x 203 mm) |
| Weight | 0.66 lb (300 g) |
