Wirelessly receives and pass measurements from the i410 or i1010 AC/DC clamps accessories and other Fluke Connect™ enabled master units with this wireless AC/C current module.
Wirelessly receives and pass measurements from the i410 or i1010 AC/DC clamps accessories and other Fluke Connect™ enabled master units with this wireless AC/C current module.
Features
| AC/DC Current | |
| Function | A dc A ac |
| Range | 1000 A 600 A |
| Resolution | 0.1 A 0.1 A |
| Accuracy | [0.5% + 3] [1.0% + 3] |
| General Specifications | |
| Maximum Voltage Between Terminal and Earth Ground (Module) | 30 V dc or ac rms |
| LCD with Backlight | 3½ 6000 counts 4/sec to 1 hr Default 1 min |
| Log Rate/Interval | Adjustable by PC from 1 sec to 1 hr, default 1 min |
| Memory | Record up to 65,000 readings |
| RF Communications | 2.4 GHz ISM Band |
| RF Communication Range | Open air, unobstructed: Up to 65.62' (20 m) Obstructed, sheetrock wall: Up to 21.33' (6.5 m) Obstructed, concrete wall or steel electrical enclosure: Up to 11.5' (3.5 m) |
| Operating Temperature | 14 to 122°F (-10 to 50°C) |
| Storage Temperature | -40 to 140°F (-40 to 60°C) |
| Temperature Coefficient | 0.1 x (specified accuracy)/°C (<18°C or >28°C) |
| Relative Humidity | 0 to 90% 32 to 95°F (0 to 35°C) 0 to 75% 95 to 104°F (35 to 40°C) 0 to 45% 104 to 122°F (40 to 50°C) |
| EMC | IEC 61236-1, Portable |
| Safety Compliance | Protected to IEC 61010-1, 600 V CAT IV / 1000 V CAT III, 3rd edition Pollution Degree 2 |
| Certifications | CSA, CE, FCC: T68-FBLE IC: 6627A-FBLE |
| Ingress Protection (IP) Rating | IP42 |
| Battery Type | 2 x AA alkaline batteries, NEDA 15A, IEC LR6 |
| Battery Life | 400 hours minimum |
| Dimensions | 6.3 x 2.6 x 1.5" (160 x 66 x 38 mm) |
| Weight | 0.56 lb (255 g) |
Fluke engineers have delivered an innovative mobile platform and tool that helps solve everyday problems, allowing you to instantly document measurements, retrieve historical data, and share live measurements with your team. All handled by the Android™ or iOS smart phone you already carry.
Fluke Connect with ShareLive™ video call is the only wireless measurement system that lets you stay in contact with your entire team without leaving the field. The Fluke Connect mobile app is works with over 20 different Fluke products - the largest suite of connected test tools in the world.
Make the best decisions faster than ever before by viewing temperature, mechanical, electrical and vibration measurements for each equipment asset in one place. Get started saving time and increasing your productivity.
