CPS MD100WVHE 4-Valve Wireless Digital Manifold with Clamp Probes, Vacuum Gauge

Modèle: MD100WVHE

CPS MD100WVHE 4-Valve Wireless Digital Manifold with Clamp Probes, Vacuum Gauge-

Télécharger: datasheet manual

Plus de produits CPS

Demander à un expert

CPS MD100WVHE 4-Valve Wireless Digital Manifold with Clamp Probes, Vacuum Gauge

Modèle: MD100WVHE

This 4-valve digital manifold has fast and convenient touch-screen control with a 5ft (150cm) hose set.

This 4-valve digital manifold has fast and convenient touch-screen control with a 5ft (150cm) hose set.

Prix spécial $1394.40 CAD
Prix régulier $1680.00 CAD
Disponibilité 2 à 3 semaines
Quantité

CPS MD100WVHE Offers

Can be used as conventional manifolds or connect wirelessly with any iOS or Android mobile device using the Manifold Link™ app.

Features

  • Connects with the CPS Link app
  • Perform and monitor full system measurements—in real time
  • Fast, convenient touch screen control
  • Perform select manifold functions without the need to physically touch the manifold
  • Data logging
  • Alternate views for smaller mobile devices
  • Color scheme change according to refrigerant
  • Real-time information displayed on screen
  • Perform multiple system tests
  • Pressure hold or vacuum hold tests can be viewed, saved, stored or emailed as a graph
  • Supports 105 of the most common refrigerants, with quick access to your favorite five
  • APP updates for new refrigerants
  • Change manifold units; (Pressure, Temperature, Vacuum)
  • Multi-language
  • Water-resistant, high-strength, glass-filled nylon housing
  • Precision machined anodized aluminum manifold body
  • Proprietary Vortech® valve systems (certified to 10 microns)
  • 2 Pressures, 2 temperatures and vacuum (using MDXVG accessory)
  • Vacuum hold and pressure hold test functions
  • US Patent No. 9,043,161

App Features

  • Comprehensive views of system measurements
  • Graphical depictions of test functions
  • Data logging
  • Geolocation data

CPS MD100WVHE Specifications

Pressure Range High side: -14.5 to 800.0 psig (-1.0 to 55 bar)
Low side: -14.5 to 800.0 psig (-1.0 to 55 bar)
Pressure Reading Accuracy: ±1% of readings (±0.5 psig or ±0.05 bar)
Resolution: 0.5 psig (0.05 bar)
High and Low Side Burst Pressure 1500 psig (103.4 bar)
Temperature Range High side: -58 to 302°F (-50 to 150°C)
Low side: -58 to 302°F (-50 to 150°C)
Temperature Reading Accuracy ±0.36°F (±0.2°C)
Vacuum Indication Accuracy ±10 microns (requires MDXVG accessory)
SH, SC & Saturation Temperature Accuracy ±0.5°F (±0.3°C)
Instrument Working Temperature -4 to 122°F (-20 to 50°C)
Communication Range (with CPS Link™) Up to 300 ft (91.44 m) (Depends on device capabilities)
Instrument Working RH Range 0% to 100% non-condensing
APO (Automatic Power Off) 10 min (Can be disabled by user)
Display Life 4 x industrial alkaline AA batteries with backlight on: 25+ hrs continuous duty
4 x industrial alkaline AA batteries with backlight off: 60+ hrs continuous duty
4 x rechargeable NiHM AA batteries with backlight on: 20+ hrs continuous duty (not included)
4 x rechargeable NiHM AA batteries with backlight off: 50+ hrs continuous duty (not included)
Dimensions 8.1 x 3.5 x 7" (20.5 x 8.9 x 17.8 cm)
Weight 3.3 lbs (1.5kg)
Cliquer ici pour toutes les spécifications du CPS MD100WVHE

What's included with the CPS MD100WVHE

  • 4-Valve Wireless Digital Manifold
  • Thermistor Sensor with 6' Leads (MDXCP) X 2
  • 5' Black & Chrome Ball Valve Charging Hoses 3Pk (HP5BKEZ)
  • 5' Heavy Duty Black & Chrome Vacuum Hose
  • Vacuum Gauge Accessory Kit (MDXVG)
  • 4 x AA Industry Alkaline Batteries
  • User Manual
datasheet pour le CPS MD100WVHE 4-Valve Wireless Digital Manifold with Clamp Probes, Vacuum Gauge manual pour le CPS MD100WVHE 4-Valve Wireless Digital Manifold with Clamp Probes, Vacuum Gauge

Poser une question sur le CPS MD100WVHE 4-Valve Wireless Digital Manifold with Clamp Probes, Vacuum Gauge

CPS MD100WVHE Offers

Can be used as conventional manifolds or connect wirelessly with any iOS or Android mobile device using the Manifold Link™ app.

Features

  • Connects with the CPS Link app
  • Perform and monitor full system measurements—in real time
  • Fast, convenient touch screen control
  • Perform select manifold functions without the need to physically touch the manifold
  • Data logging
  • Alternate views for smaller mobile devices
  • Color scheme change according to refrigerant
  • Real-time information displayed on screen
  • Perform multiple system tests
  • Pressure hold or vacuum hold tests can be viewed, saved, stored or emailed as a graph
  • Supports 105 of the most common refrigerants, with quick access to your favorite five
  • APP updates for new refrigerants
  • Change manifold units; (Pressure, Temperature, Vacuum)
  • Multi-language
  • Water-resistant, high-strength, glass-filled nylon housing
  • Precision machined anodized aluminum manifold body
  • Proprietary Vortech® valve systems (certified to 10 microns)
  • 2 Pressures, 2 temperatures and vacuum (using MDXVG accessory)
  • Vacuum hold and pressure hold test functions
  • US Patent No. 9,043,161

App Features

  • Comprehensive views of system measurements
  • Graphical depictions of test functions
  • Data logging
  • Geolocation data
En savoir plus...

CPS MD100WVHE Specifications

Pressure Range High side: -14.5 to 800.0 psig (-1.0 to 55 bar)
Low side: -14.5 to 800.0 psig (-1.0 to 55 bar)
Pressure Reading Accuracy: ±1% of readings (±0.5 psig or ±0.05 bar)
Resolution: 0.5 psig (0.05 bar)
High and Low Side Burst Pressure 1500 psig (103.4 bar)
Temperature Range High side: -58 to 302°F (-50 to 150°C)
Low side: -58 to 302°F (-50 to 150°C)
Temperature Reading Accuracy ±0.36°F (±0.2°C)
Vacuum Indication Accuracy ±10 microns (requires MDXVG accessory)
SH, SC & Saturation Temperature Accuracy ±0.5°F (±0.3°C)
Instrument Working Temperature -4 to 122°F (-20 to 50°C)
Communication Range (with CPS Link™) Up to 300 ft (91.44 m) (Depends on device capabilities)
Instrument Working RH Range 0% to 100% non-condensing
APO (Automatic Power Off) 10 min (Can be disabled by user)
Display Life 4 x industrial alkaline AA batteries with backlight on: 25+ hrs continuous duty
4 x industrial alkaline AA batteries with backlight off: 60+ hrs continuous duty
4 x rechargeable NiHM AA batteries with backlight on: 20+ hrs continuous duty (not included)
4 x rechargeable NiHM AA batteries with backlight off: 50+ hrs continuous duty (not included)
Dimensions 8.1 x 3.5 x 7" (20.5 x 8.9 x 17.8 cm)
Weight 3.3 lbs (1.5kg)
Cliquer ici pour toutes les spécifications du CPS MD100WVHE

What's included with the CPS MD100WVHE

  • 4-Valve Wireless Digital Manifold
  • Thermistor Sensor with 6' Leads (MDXCP) X 2
  • 5' Black & Chrome Ball Valve Charging Hoses 3Pk (HP5BKEZ)
  • 5' Heavy Duty Black & Chrome Vacuum Hose
  • Vacuum Gauge Accessory Kit (MDXVG)
  • 4 x AA Industry Alkaline Batteries
  • User Manual
datasheet pour le CPS MD100WVHE 4-Valve Wireless Digital Manifold with Clamp Probes, Vacuum Gauge manual pour le CPS MD100WVHE 4-Valve Wireless Digital Manifold with Clamp Probes, Vacuum Gauge

Poser une question sur le CPS MD100WVHE 4-Valve Wireless Digital Manifold with Clamp Probes, Vacuum Gauge
