Monitor the pressure in your boiler, pump or compressor with this gauge. The gauge features a 3.5in (8.89mm) dial to measure pressure from 0 to 50psi.
Monitor the pressure in your boiler, pump or compressor with this gauge. The gauge features a 3.5in (8.89mm) dial to measure pressure from 0 to 50psi.
You can easily track the pressure in your boiler, pump, compressor or hydraulic equipment with this Ashcroft 351009SW02L50# Duralife Pressure Gauge. The gauge is capable of measuring 0 to 50 psi on the 3.5" (8.89 cm) dial. PowerFlex™ movement is resistant to shock, vibrations and pulsation for reliable performance.
Features
Applications
| Measurement Range | 0 to 50 psi |
| Accuracy | ±1% of span (dry), ±1.5% of span (liquid filled) |
| Dial Size | 3.5" (8.89 cm) |
| Socket Material | Stainless steel |
| Case Material | Stainless steel |
| Movement | PowerFlex |
| RoHS Compliant | Yes |
| Wetted Material | 316L SS tube, 316L SS socket |
| Window | Polycarbonate |
| Pointer | Adjustable aluminum |
| Connection Type | 1/4" NPT male |
| Measurement Range | 0 to 50 psi |
| Accuracy | ±1% of span (dry), ±1.5% of span (liquid filled) |
| Dial Size | 3.5" (8.89 cm) |
| Socket Material | Stainless steel |
| Case Material | Stainless steel |
| Movement | PowerFlex |
| RoHS Compliant | Yes |
| Wetted Material | 316L SS tube, 316L SS socket |
| Window | Polycarbonate |
| Pointer | Adjustable aluminum |
| Connection Type | 1/4" NPT male |
