Kari cable suspended float switches provide up to four switching levels in a single float and offer 25 different configurations- some have included with them a built in hysteresis; which means you can replace up to four single level switches with one-4 point level switch. Kari float switches hold high chemical compatibility and durable components built to outlast any other.
Kari cable suspended float switches provide up to four switching levels in a single float and offer 25 different configurations- some have included with them a built in hysteresis; which means you can replace up to four single level switches with one-4 point level switch. Kari float switches hold high chemical compatibility and durable components built to outlast any other.
Function
Float switches open and close contacts to control whether or not signal current can pass through, they work like a standard light switch. They are either normally closed, meaning current is flowing, or normally open, meaning current is not flowing. The "normal" state is when the float switch is down, resting on it's cable or float stop.
Features
Versatile and Reliable Float Switch
Applications
| Switching Differential | Minimum: 10" (25.4 cm) Maximum: 50" (127 cm) |
| Maximum Liquid Temperature | Standard: 130°F (54°C) Optional: 175°F (80°C) |
| Protection Rating | IP67, NEMA 6 |
| Programming | N/A 19 control configurations available |
| Minimum Fluid Specific Gravity | Standard Float: 0.7 Mini Float: 0.95 |
| Standard Cable Lengths | 16' (5 m) 49' (15 m) |
| Weight | 1.3 to 4 lbs (varies on type) |
| Maximum Voltage | 250 V AC or DC |
| Material | Float: Polypropylene Cable: Standard - PVC, Optional - Rubber, PTFE (Teflon®), TPU (Oil resistant) |
