PS-45 series DIN rail mountable power supply with 24 VDC 2 A output and 48 W rated power. Low profile with single output class II and includes overload, overvoltage, and overtemperature protections.
PS-45 series DIN rail mountable power supply with 24 VDC 2 A output and 48 W rated power. Low profile with single output class II and includes overload, overvoltage, and overtemperature protections.
Discontinué!
Ce produit a été discontinué et n’est plus disponible.
Il n’y a pas de remplacement direct, mais nous vous recommandons:
Vous ne trouvez pas ce que vous cherchez? Nous ferons une recherche et vous aiderons à trouver ce dont vous avez besoin.
Caractéristiques
| DC Voltage and rated current Output | 24 V, 0 to 1.5 A |
| Rated Power | 36 W |
| Ripple & Noise (max) | 150 mVp-p |
| Voltage Adj. Range | 21.6 to 26.4 V |
| Voltage Tolerance | ±1.0% |
| Input Voltage Range | 85 to 264 VAC |
| Input Frequency Range | 47 to 63 Hz |
| Overload Protection | 105 to 160% rated output power |
| Overvoltage Protection | 27.6 to 32.4 V |
| Working Temperature | -4 to 140°F (-20 to 60°C) |
| DC Voltage and rated current Output | 24 V, 0 to 1.5 A |
| Rated Power | 36 W |
| Ripple & Noise (max) | 150 mVp-p |
| Voltage Adj. Range | 21.6 to 26.4 V |
| Voltage Tolerance | ±1.0% |
| Input Voltage Range | 85 to 264 VAC |
| Input Frequency Range | 47 to 63 Hz |
| Overload Protection | 105 to 160% rated output power |
| Overvoltage Protection | 27.6 to 32.4 V |
| Working Temperature | -4 to 140°F (-20 to 60°C) |
