Weiss 35RB220-10 Panel Mount Thermometer with 10' Capillary, 20 to 220° F

Model: 35RB220-10

Be the first to review this product

Weiss 35RB220-10 Panel Mount Thermometer with 10' Capillary, 20 to 220&deg; F-

Downloads: datasheet

More Weiss Products

Ask an Expert

Weiss 35RB220-10 Panel Mount Thermometer with 10' Capillary, 20 to 220° F

Model: 35RB220-10

Be the first to review this product

This panel mount vapour filled dial thermometer indicates temperature in remote or inconvenient places via minimum 5-foot sensor cable. Simply insert the sensor bulb in the environment to be measured and mount the dial in an accessible location. Back connection capillary and forward flange for panel mounting.

Discontinued!

This product has been discontinued and is no longer available. There are no replacement options.

We can help you find what you need:

Weiss 35RB220-10 Capillary Remote Reading Thermometer Offers

Features

These vapour filled dial thermometers indicate temperatures in remote or inconvenient places via a minimum 5-foot sensor cable
Simply insert the sensor bulb in the environment to be measured and mount the dial in an accessible location
Standard instruments supplied with 3/32" bronze armored copper capillary tubing, 6" brass sensing bulb and 1/2" NPT brass union (Other Lengths Available)
Standard thermometers furnished with bottom connection capillary and recessed flange for surface mounting (35BL Series)
Also available with back connection capillary and forward flange for panel mounting (35RB Series)
White 3-1/2" diameter dial with black graduations; non-linear scales
Dual scale, all thermometers feature Fahrenheit range listed as well as Celsius equivalent
Accuracy ±0.05% of full scale reading
Can be inclined at any angle without loss of accuracy

Applications

Ideal for the following applications: OEM, Industrial, Educational, Food Service, Laboratory

Weiss 35RB220-10 Specifications

Case and Ring	Drawn stainless steel case with snap-in "O" ring gasketed clear lexan window
Case Styles	Five case styles are available (as shown) to accommodate direct mount, surface or panel mounting
Dial	White coated aluminum with black markings
Pointer	Slotted adjustable type
Bourdon Tube	Phosphor bronze
Thermal Bulb & Line Assembly	Copper of 316 stainless steel
Accuracy	One scale division throughout range

Click here for complete specifications on the Weiss 35RB220-10

What's included with the Weiss 35RB220-10

Weiss 35RB220-10 Panel Mount Thermometer with 10' Capillary, 20 to 220° F

datasheet for the Weiss 35RB220-10 Panel Mount Thermometer with 10' Capillary, 20 to 220° F

Ask a question about Weiss 35RB220-10 Panel Mount Thermometer with 10' Capillary, 20 to 220° F

Customer Reviews for the Weiss 35RB220-10

Description ➕➖

Weiss 35RB220-10 Capillary Remote Reading Thermometer Offers

Features

These vapour filled dial thermometers indicate temperatures in remote or inconvenient places via a minimum 5-foot sensor cable
Simply insert the sensor bulb in the environment to be measured and mount the dial in an accessible location
Standard instruments supplied with 3/32" bronze armored copper capillary tubing, 6" brass sensing bulb and 1/2" NPT brass union (Other Lengths Available)
Standard thermometers furnished with bottom connection capillary and recessed flange for surface mounting (35BL Series)
Also available with back connection capillary and forward flange for panel mounting (35RB Series)
White 3-1/2" diameter dial with black graduations; non-linear scales
Dual scale, all thermometers feature Fahrenheit range listed as well as Celsius equivalent
Accuracy ±0.05% of full scale reading
Can be inclined at any angle without loss of accuracy

Applications

Ideal for the following applications: OEM, Industrial, Educational, Food Service, Laboratory

Specifications ➕➖

Weiss 35RB220-10 Specifications

Case and Ring	Drawn stainless steel case with snap-in "O" ring gasketed clear lexan window
Case Styles	Five case styles are available (as shown) to accommodate direct mount, surface or panel mounting
Dial	White coated aluminum with black markings
Pointer	Slotted adjustable type
Bourdon Tube	Phosphor bronze
Thermal Bulb & Line Assembly	Copper of 316 stainless steel
Accuracy	One scale division throughout range
