Meets the required specifications for diagnostic and educational use, this clinical microscope is perfect for clinics, universities, and industrial laboratories. Comes in a monocular viewing head and objectives with 4x, 10x, 40x, and 100x magnification.
Meets the required specifications for diagnostic and educational use, this clinical microscope is perfect for clinics, universities, and industrial laboratories. Comes in a monocular viewing head and objectives with 4x, 10x, 40x, and 100x magnification.
Discontinued!
This product has been discontinued and is no longer available. There are no replacement options.
We can help you find what you need:
Features
Applications
| Optical System Type | Monocular |
| Eyepiece | Magnification: 10x Type: Widefield Field Diameter: 0.7" (18 mm) |
| Nosepiece | Positions: 4 Pitch: Reverse |
| Illumination | Technique: Brightfield Type: Achromatic |
| Objective Magnification | 4x, 10x, 40x, 100x |
| Stage | Type: Mechanical Shape: Rectangular Dimensions: 6.3 x 5.5" (160 x 140 mm) |
| Focusing | Type: Coaxial Controls: Coarse/fine Range: 1.6" (40 mm) |
| Condenser | Type: Abbe 1.25 N.A. w/ Iris Diaphragm Focusing Control: Rack & Pinion |
| Illumination | Type: 20W Variable quartz halogen Koehler: Field Diaphragm Filter Holder: On Collector |
| Dimensions | 8.27 x 7.09 x 14.97" (210 x 180 x 380 mm) |
| Weight | 15.4 lbs (7.0 kg) |
