NOSHOK 854-MC Soft Tip Bleed Needle Valve, Male/Steel, ½" NPT

Model: 854-MC

Be the first to review this product

$NOSHOK 854-MC Soft Tip Bleed Needle Valve, Male/Steel, &frac12;&quot; NPT-$

Downloads: datasheet

More NOSHOK Products

Ask an Expert

NOSHOK 854-MC Soft Tip Bleed Needle Valve, Male/Steel, ½" NPT

Model: 854-MC

Be the first to review this product

The soft tip bleed needle valve provides a convenient means to relieve process pressures trapped between a shut-off valve and the instrument. It uses bonnet assemblies with an integrated single-threaded body for insertion in vent port. It comes in zinc-nickel plated steel.

Your Price	$69.00 CAD
Availability	2 to 3 Weeks
Quantity	Quantity

NOSHOK 854-MC Offers

Features

100% helium leak tested to 1 x 10^-4 ml/s for guaranteed performance and reliability 10,000 psi hard seat pressure rating at 200°F
FKM o-ring seal and PTFE back-up ring below the stem threads to protect from corrosion and galling; PTFE or Graphite packing optional
All stem threads are rolled for strength and ease of operation
0.159" bleed port

NOSHOK 854-MC Specifications

Pressure Rating	10,000 psi @ 200°F
Bleed Port	0.159"
Options	Panel mountings, o-ring materials, handles, packings, regulating stem and stem tips
Connection Size	Delrin soft tip ½" NPT
Valve Type	Male, steel
Material	Zinc-nickel plated steel
Weight	Approximately 0.4 lb.

Click here for complete specifications on the NOSHOK 854-MC

What's included with the NOSHOK 854-MC

NOSHOK 854-MC Soft Tip Bleed Needle Valve, Male/Steel, ½" NPT

datasheet for the NOSHOK 854-MC Soft Tip Bleed Needle Valve, Male/Steel, ½" NPT

Ask a question about NOSHOK 854-MC Soft Tip Bleed Needle Valve, Male/Steel, ½" NPT

Customer Reviews for the NOSHOK 854-MC

Description ➕➖

NOSHOK 854-MC Offers

Features

100% helium leak tested to 1 x 10^-4 ml/s for guaranteed performance and reliability 10,000 psi hard seat pressure rating at 200°F
FKM o-ring seal and PTFE back-up ring below the stem threads to protect from corrosion and galling; PTFE or Graphite packing optional
All stem threads are rolled for strength and ease of operation
0.159" bleed port

Specifications ➕➖

NOSHOK 854-MC Specifications

Pressure Rating	10,000 psi @ 200°F
Bleed Port	0.159"
Options	Panel mountings, o-ring materials, handles, packings, regulating stem and stem tips
Connection Size	Delrin soft tip ½" NPT
Valve Type	Male, steel
Material	Zinc-nickel plated steel
Weight	Approximately 0.4 lb.
