Ideal for hydraulics and pneumatics, the high-quality brass liquid-filled pressure gauge has a range from 0 to 60 psi. Come with a 2½" (63.5 mm) die-cast brass case and ¼" NPT brass bottom connection.
Ideal for hydraulics and pneumatics, the high-quality brass liquid-filled pressure gauge has a range from 0 to 60 psi. Come with a 2½" (63.5 mm) die-cast brass case and ¼" NPT brass bottom connection.
Features
Applications
| Pressure Range | 0 to 60 psi |
| Accuracy | ±1.6% full scale |
| Gauge Size | 2½" (63.5 mm) |
| Measuring Element | Copper alloy C tube |
| Case | Die-cast brass (natural brass finish) with safety relief plug |
| Lens | Acrylic with o-ring seal |
| Connection | ¼" NPT die-cast brass with the case. 7⁄16" - 20 SAE adjustable type straight thread with FKM O-ring is also available as a stock option on many ranges (-4 SAE) |
| Pointer | Balanced aluminum, black finish |
| Dial | Aluminum, white background with black scale, UV resistant |
| Movement | Brass and nickel-silver with highly polished bearing surfaces |
| Liquid Fill | Glycerin |
